R44 Helicopters Featured in Movie Poster

Low budget production?

We attempted to see Avatar in 3D yesterday at the local AMC movie theater. There weren’t 2 seats together in the entire theater, so we got a refund and left. I’m not paying $25 to watch a 2-1/2 hour movie sitting in crap seats halfway across the theater from my husband.

Movie Poster for The Spy Next DoorAnyway, outside the theater were movie posters for coming attractions, including this one for an upcoming Jackie Chan movie called The Spy Next Door. And it doesn’t take a helicopter expert to recognize all three helicopters in the poster are R44s.

This is the first time I can remember seeing a Robinson helicopter in a movie poster.

Eventually, we’ll see the movie. I don’t think we’ll see it in theaters. Frankly, it doesn’t look very good — just the usual family farce. We like Jackie Chan — his comic style of martial arts fighting was showcased perfectly in the first Rush Hour movie — but goofy slapstick turns me off and I have a hunch this flick will be full of it. (Gotta keep the kids entertained, after all.) We’ll see it when it hits Netflix.

R44s in Poster

Detail from poster. With a tag line like this, I’m not likely to rush out and see the movie.

Mike and I were wondering why R44s are featured in the poster (and likely, the movie). Let’s face it: they don’t look nearly as slick as some of the turbine helicopters that usually appear in movies. Mike thinks they needed several helicopters for the movie and R44s were a good low budget alternative.

I’m thinking that depending on how the helicopters are used — or abused — it might be good exposure for Robinson products.

I’m pleased to see R44s so prominently displayed on the poster. I’m just hoping they belong to the good guys and don’t end up as fireballs — as so many movie helicopters do.

About My New Fifth Generation iPod Nano

Holy cow!

Yesterday, my Fifth Generation iPod — approximately equal to what they’re now calling an iPod Classic — the first version to support video — died again. I have a tendency to let the battery drain completely and sit in my purse like that. Then, when I attempt to sync, my Mac doesn’t know what the heck it’s connected to and wants to restore it.

This is the fifth time this has happened and the third time it has happened in the past two months. When I left for an appointment yesterday, it was still connected to my Mac, trying to import about 25GB of podcasts and music and videos. It was taking a long time, so I left it.

Coincidentally, that appointment was at the Biltmore Apple Store, which is walking distance from our “Rear Window” apartment in Phoenix. I was bringing in my 12″ PowerBook, which had a dead hard disk. I wanted to know what it would cost to replace the disk. I learned a few things:

  • The 12″ PowerBook computer was first manufactured in early 2003.
  • I bought mine in July 2003.
  • On a 12″ PowerBook, you must remove 23 screws to get at and remove the hard disk. You then have to screw them all back in. In the right places.
  • Apple has absolutely no interest in repairing 6-year-old laptops.

I’ll blog more about my solution to this another time. Let me get back to my new Nano.

Of course, I hadn’t bought it yet. But I figured that since I was there, I may as well take a look.

iPod Nano

This isn’t my Nano, my thumb, or a video of anyone I know. But mine looks a lot like this one.

And I liked what I saw. So I bought a 16 GB red one. Yes, it’s (product)red, so a portion of the purchase price goes to fight AIDS in Africa. But that’s not why I picked red. I just like red. I’d like to help fight AIDS in Africa, but they’d get a lot less money from me if it was (product)turquoise.

Understand this: I bought a new iPod to replace one that simply wasn’t functioning reliably. The idea was to buy an iPod that would work with the iPod setup in my car and elsewhere. (The Shuffle won’t.)

I liked the idea of video, but since the video feature sucked battery power in my old iPod, I didn’t use it often. I didn’t expect to use it much on this iPod either.

All I wanted was something I could use to listen to podcasts and music while I drove or flew.

I got so much more.

This little sucker is absolutely packed with features.

  • It plays MP3s and other audio format files.
  • It plays movies.
  • It has an FM radio tuner built in. The FM tuner can identify songs so you can tag them and later sync them with your computer for easy shopping on the iTunes Store.
  • It has a video camera.
  • It has a pedometer. It can sync up with Nike’s Web site for some reason I’m not clear about and probably wouldn’t care about if I did.
  • It has games.
  • It can tell when you tilt it so it orients the screen properly. This tilt thing can also be used by games.
  • It can record voice memos.
  • It can store and display photos.
  • It can sync with Address Book and iCal on my Mac.
  • It can store notes.

It does a huge amount of stuff I didn’t expect. And every time I find something new, I get all giddy, like a kid.

Playing with one of these silly things for the first time — as an owner — is better than opening presents at Christmas.

Now I know what you’re saying. “Maria, you work with Apple products all the time. Didn’t you know that the Nano had all these features?”

No, I didn’t. I mean I knew about the movies and heard about the built-in video camera. But the tilt thing and games and pedometer and radio were all quite a shock.

Maybe you’re saying, “Maria, how could you spend nearly $200 and not know what you’re getting?”

Well, I thought that what I thought I was getting was worth $200. The Nano comes in a really sleek little package. Weighs next to nothing. Incredible quality video for such a tiny screen. I was satisfied.

Now I’m beyond that.

Do all MP3 players have this many bells and whistles? What have I been missing?

As you might imagine, I’m very happy with my new purchase. The only adjustment I’ll need is limiting the data I put on it to less than 16 GB. My old iPod has a 30 GB hard disk in it; this is quite a step down.

But I’ll deal with it.

Religulous

A movie review.

ReligulousI just watched Bill Maher’s documentary, Religulous. It’s been in my Netflix queue for some time now and I recently let it ride to the top. I watched it on my second monitor while doing some relatively mindless work on the other.

The movie was just what I expected: Bill Maher trying to talk reason to religious zealots. While his breakaways to movie scenes and comic subtitles were generally amusing, much of the rest of the movie was quite disturbing. It isn’t Maher’s views that bother me — I share them. It’s the stubbornness of the religious zealots he spoke to. They simply did not want to listen to reason.

Want some specific examples?

He spoke with Christians about Jesus and pointed out that an ancient Egyptian god named Horus shared much of Jesus’s history, from virgin birth to crucifixion and resurrection. This is documented in ancient Egyptian writing. Yet the Christians refused to acknowledge that the Egyptian myths exist. How can they be so stubborn?

He pointed out to Christians that the New Testament, which forms the basis of Christianity and Christian beliefs says nothing about homosexuality being a sin. He pointed out other things that are and are not in the Bible. If what he said contradicted current Christian beliefs, however, these people denied what he said. They clearly had no clue what was in the holy scriptures they swore was the word of god.

He pointed out to Muslims that the Koran contains multiple references about violence against non-Muslim “infidels.” They either denied the meaning of those references or tried to claim that they applied to another time.

He had similar confrontations with Jews, Mormons (and ex-Mormons), and members of other religions.

This went on for nearly two hours.

This was exactly what I expected and, to be honest, I didn’t enjoy it very much. It’s an argument he’ll never win. None of the atheists will. People have faith — blind faith in whatever it is that they believe. They ignore the evidence that they’re wrong. They go on believing, thinking that they’ll be rewarded someday while the non-believers — or the people that believe in Brand X religion — will be punished.

Meanwhile, they keep fighting and hating and killing and keeping their women and children in the dark ages intellectually — all in the name of their god.

It makes me sick.

I’m not quite sure what Maher intended to do with this movie. He’s obviously not going to convert anyone. There wasn’t enough comedy to make it fun to watch. Was he just trying to give atheists a bit of support in their quest for reason? To convince us to speak out as he has?

What’s the point?

This reminds me of a post I read last week on Think Atheist, “Why Talk About It?.” In it, the blogger compares religion to collecting stamps:

When you are in safe company, you poke fun at the stamp collectors and their silly beliefs. You find comfort in the fact that you are not the only sane person around. In a world of stamp collectors, you are one of only a few non-stamp collectors.

Maybe that’s what Religulous was all about: To remind us that we’re not the only ones who don’t collect stamps.

Sunset / Moonset Time-Lapse

Oh, I’ve got it bad.

I really feel almost addicted to making these movies. I know they’re not really any good, but I think they’re interesting (at least). And they’re helping me to understand how to create time-lapse movies, what works, and what doesn’t work.

Yesterday afternoon, I set up my camera and time-lapse equipment on the upstairs patio of my house, pointing at the sunset. Then I let it go, shooting one image every 20 seconds. It was nearly 11 PM when I turned it off. By that time, the crescent moon had set, too.

The resulting video included a lot of blank sky. My exposure was not lengthy enough to capture the stars after sunset, although one very bright star does set with the moon when it finally makes its appearance. I cut the video into two pieces: sunset and moonset. Here they are.

Sunset Time-Lapse

It was a pretty good afternoon for shooting the sunset. In Arizona, we don’t get clouds very often — although this year, our annual monsoon may be starting early. Yesterday afternoon, there were a lot of clouds out to the west — enough to completely filter the sun and give it something to paint with color as it set.

I should mention here that this is the same sky you can see in the time-lapse I did earlier in the day of the saguaro flowers. I just moved the camera upstairs and excluded anything other that the sky (and a tiny bit of a distant tree — darn it!). The only thing I wish is that I’d begun the time-lapse before the sun entered the camera’s frame. I think it would have been more interesting to see it drift in and then set.

I also need to point out that this video (and the one with the cactus flowers) really illustrates what I find attractive about time-lapse photography. It isn’t showing us anything we can’t see on our own. But it’s speeding up the process, making it possible to see motion where we normally wouldn’t. For example, this video is 20 seconds long. I created it using images spaced 20 seconds apart, then put them together in a 15 frames per second video. Do the math: 15 x 20 x 20 = 6000 seconds of real time. That’s 100 minutes. Would you sit still for 1 hour and 40 minutes to watch a sunset? And, if you did, would you see the clouds and sun moving as they clearly are in the video?

Moonset Time-Lapse

I cut out all the boring black night sky to produce this short video of the setting crescent moon. Not terribly exciting, I’m afraid.

One of the things I learned here is to set the exposure manually so all shots are the same. Let’s face it — the brightness of the image shouldn’t change. One exposure should do the trick. If I’d made a longer exposure, I would have had a brighter moon and more stars. And if I’d fixed the exposure to be the same for every shot, the brightness of the moon wouldn’t change from one shot to the next. (I sure hope some more knowledgeable photographers out there will correct me if I’m wrong on this.)

What Do You Think?

I’d love to get your feedback about my time-lapse mania. Are you enjoying them as much as I am? Am I wasting my time? Do you have any specific topics you’d like to see in time-lapse? Use the Comments link for this post or any of the other time-lapse posts to let me know.

On Helicopters, Video, and Stabilization

A few lessons learned.

September 2010 Update:
Flying M Air is now the proud owner of a gyro-stabilized Moitek video camera mount, which is available to aerial photography clients. Learn more about this mount here.

Those of you who have been following this blog know that I’ve been working on a series of video projects for some time now. The projects were stalled for a number of reasons — raw video that remained uncataloged, miscommunication between me and the video crew, the holidays, and the discovery that much of the video we needed was either not acquired during our October shoot or was of insufficient quality to move forward on the projects.

This whole thing has been a huge learning experience for me in so many ways. And I’m sure that someday, I’ll blog about some of the other lessons I learned the hard way.

Today, however, I want to focus on the lessons I learned about capturing video from a helicopter. This is a long post, but I think it’s worth reading if you have any interest in shooting video from a helicopter without spending a fortune on equipment.

The Camera

Back in December or January, when I’d cataloged about 2/3 of the raw video that had been shot in October, I realized that we needed to “make up” some shots. For reasons I’d prefer not to go into here, I decided that it would probably be better for Mike and I to fly up to the location — Lake Powell near Page, AZ — and get the missing footage ourselves.

Sony HDR-CX12 HandycamI’d bought a Sony HDR-CX12 Handycam before Christmas in preparation for getting some of the footage we’d need for the projects. At the time, I didn’t expect we’d need to capture so much of it. Had I known, I might have chosen a different camera. But the quality of images from the Handycam is truly amazing — a fact we discovered when we hooked it up to an HD TV with a HDMI cable in January. Holy cow!

I should mention a few things about this camera.

  • It’s amazingly small and light. Weighing in at 1 pound, 4 ounces on my postal scale, it’s like holding nothing. My digital SLR with the 16-200 lens it normally wears is a good 3 times the weight.
  • It does not have a viewfinder. Instead, you frame your images by looking at a tiny LCD monitor. This might not be the best solution for folks who have trouble focusing on things close to their faces.
  • It uses Memory Stick PRO Duo media, which are tiny little cards that go into a slot at the bottom of the camera. I’d bought a bunch of 4GB cards so I could easily archive each card to a single layer DVD. As a result, we could record only 28 minutes of high-definition video — we’re talking 1080i here — on each card.
  • Its wide angle view is not very wide. While this eliminates the chance of distortion, it also requires that the subject be far enough away to fit into the camera’s view.
  • And have I mentioned that the quality of video shot with this camera is absolutely amazing? It’s equal to or better than much of the footage originally shot on this project using professional camera equipment.

The First [Re]Shoot

In late January, Mike and I flew up to Page for the day to capture some of the video that had been missed on the original shoot. This included historic Hole in the Rock and a lot of “big view” sequences of the lake. We had other business in Page — I’d bought a hangar there and wanted to give it another inspection since the previous owner left. I also had some business in the terminal building. We made a day trip of it and shot about 20 minutes of raw footage over the lake with another 10 minutes of footage over the Little Colorado River Gorge.

For this shoot we set two options on the camera:

  • Part of the original footage we needed to replace was bad because of a focusing issue. The videographer’s camera was unable to lock in focus on certain areas. As a result, every fifth or tenth or twentieth frame of the video was blurry. The net effect of this was what appeared to be camera shake. But a frame-by-frame examination of the video clearly revealed the truth — the camera wasn’t focusing properly. This made video that simply could not be fixed or used. We headed off this potential problem on our camera by switching the camera to “Landscape” mode, which would automatically set focus on distant objects.
  • The camera comes with a featured called SteadyShot. The description of it in the camera’s configuration window is “Compensates for camera shake in recording.” This feature is turned on by default. It appeared comparable to the “image stabilization” feature in other camcorders. Since we were flying in a helicopter, which is known for vibrations, I figured that the SteadyShot feature would be helpful to smooth out the video.

We got home and I looked at the footage. To say I was extremely disappointed is an understatement. As you can see in the following representative clip, the SteadyShot feature hadn’t done enough to steady the video. What we’d shot was mostly unusable.

[qt:https://aneclecticmind.com/wp-content/movies/FirstShoot.mov https://aneclecticmind.com/wp-content/movies/FirstShoot-poster.mov 480 286]

The Gyros

Time marches on. The project was going nowhere fast. There were other difficulties that, again, I prefer not to detail here. Things were getting ugly. And a client I’d promised a 4-6 minute video clip from the final video was calling, asking when I’d deliver. I needed to get the project done. I needed to start bringing in some revenue to cover my losses.

KS-4 Gyro StabilizerSo I did some research on gyro mounts that could stabilize the image and get out the shake. One of my still photography clients several years ago had used a Keynon Labs Gyro Mount. I went to the Kenyon Labs Web site and called them to get some information. It appeared that the KS-4 Gyro Stabilizer might resolve the vibration/shake problem. The unit in a kit that includes power source, charger, and other accessories would cost me $2,000 to buy. I wasn’t interested in making that kind of investment until I knew whether it would do the job. Fortunately, the folks at Kenyon Labs (and their distributors) rent the gyros. I arranged a weekly rental for $200 and timed it so it would arrive midweek. We’d return to Page the following weekend.

The gyro arrived on Tuesday. I was in Phoenix that week and had brought the video camera with me. We tested it one evening by driving around in the car and shooting video out the window. While the gyro did eliminate any vibration, the video was far from steady. We thought it might have something to do with rough roads and the car’s tight suspension. But we weren’t sure.

Discouraged, I decided to try the Handycam/gyro solution from a helicopter. After all, that’s what we’d be shooting from. So I rented an R44 helicopter and pilot for a half-hour test shoot in the Phoenix area. I got back to our Phoenix apartment, plugged in the camera, and had my fears confirmed. The vibration was gone, but a wobbly roll element had been introduced. You can see what I mean in the following sample footage:

[qt:https://aneclecticmind.com/wp-content/movies/PHXTest.mov https://aneclecticmind.com/wp-content/movies/PHXTest-poster.mov 480 286]

This made perfect sense. The gyro stabilized on two axes: pitch (up and down) and yaw (right and left). Roll, the third axis, was not controlled. Since it wasn’t controlled, the camera was more likely to move that way.

If this was the quality of video I could expect, it wasn’t worth the four-hour roundtrip flight from Wickenburg to Page plus the time over the lake to do a reshoot. If I were smart, I’d cut my losses and give up on the idea of us getting the footage we needed.

LSG-2 Gyro Stabilized MountBut I’m stubborn and not willing to give up so easily. So I went back to the Web and continued researching. I e-mailed Aerial Exposures, a Keynon dealer based in New Jersey who uses their gyros from helicopters in the New York Metro area. The owner of the company, Arnie, very kindly called me back to chat about my problem. He provided a number of suggestions on holding the camera/gyro in flight. He also explained that the best solution would include two gyros on a mount — the second gyro would eliminate the roll movement. Aerial Exposures makes mounts — mostly large ones for use with big cameras in helicopters. His smallest mount, the LSG-2 (shown here), might meet my needs. He also suggested the Micro Gyro Mounts made by Blue Sky Aerials in California, which also sold and rented his mounts. He gave me the phone number for the company owner, Tom, and told me to call him.

Micro Gyro Mount HDV KS-4I called and talked to Tom. By this time, it was Thursday morning and we were supposed to head up to Page on Friday afternoon to arrive right around sunset. Tom and I talked about his Micro Gyro Mount HDV KS-4, which used two Kenyon KS-4 gyros. He’d rent me the mount with one gyro and I could use the other gyro I already had with it. That would save me money. Trouble was, Tom was out of town on assignment and wouldn’t be back in his office until that night. But he promised to put the gyro kit on a Southwest Airlines flight first thing in the morning; I could pick it up at Sky Harbor Airport around midday. (I didn’t even know you could do things like that.)

On Friday, I picked up the gyro mount and headed back up to Wickenburg. I had a billion things to do before we’d depart and didn’t even get a chance to open the case until after 4 PM. We pulled the gyro and battery charger from Kenyon out of its case and put it in the case with the Blue Sky Aerials mount. We grabbed some tools, packed up the helicopter, and took off.

It was a good thing we left when we did. It was dark when we got to Page. This isn’t a city kind of dark. It’s a dark kind of dark. Real blackness beyond the town’s lights.

The Second [Re]Shoot

We were in the air the next morning, just after dawn. I’d fly, Mike would shoot. He sat up front beside me. Both our doors were off. It was cold.

The Micro Mount was quite portable, but still heavy with nearly 7 lbs of gyros and camera attached to it. We flew all the way up the lake, stopping at Cal Black Memorial Airport to fuel up and warm up. We shot all kinds of footage we’d missed or covered poorly on the first shoot, including the Defiance House Ruins, Hole in the Rock, the Great Bend in the San Juan River, and the Rincon. It was four hours of flight and we filled all five of the 4 GB memory sticks. We landed at noon, feeling good about the shoot and starving. So we ate first, then went back to the hotel to look at what we’d shot.

It wasn’t pretty. There was still considerable shake in the images. Not a vibration and not really a roll. Just a general unsteadiness.

[qt:https://aneclecticmind.com/wp-content/movies/FirstTrySecondShoot.mov https://aneclecticmind.com/wp-content/movies/FirstTrySecondShoot-poster.mov 480 286]

We were discouraged but still not ready to give up. Mike rigged up a bungee cord system to hang the camera and mount from. This had been suggested by Kenyon, Arnie, and Tom. We had hesitated because we weren’t quite sure how to set this up. But necessity is the mother of invention, so we figured out a way. We did a late afternoon shoot and came back to the hotel to look at what we’d done. It wasn’t much better.

Sunday was forecasting high winds — up to 60 miles per hour — in the afternoon. We had two options: pack it in and head home in the morning or do another shoot in the morning before the winds picked up, relax in the afternoon, and fly home on Monday after another morning shoot. We decided to stick it out. Did I mention we were stubborn?

SteadyShot

Sometime around this time, I started thinking about the SteadyShot feature of the camera. What exactly was it?

Before embarking on this shoot, I’d used my Twitter connections and Sony’s technical support (useless) in an effort to determine whether SteadyShot should be turned on when the camera was attached to a gyro. I never got a definitive answer, but the consensus was that it wouldn’t hurt. I was starting to wonder, though.

I pulled out the manual, which I’d printed (since Sony neglected to do so) and brought along. I put on my cheaters to read the tiny print (I’d printed it 2 pages per sheet to save paper) for the fifth or sixth time:

STEADYSHOT

You can compensate for camera shake (the default setting is [ON]). Set [STEADYSHOT] to [OFF] when using a tripod (optional), then the image becomes natural.

What the hell did that mean? The Sony support person had been unable to explain in a live chat that only proved how well Indian/Pakistani support staff can use macros and scripts. There was no other information in the entire manual — 115 pages of it — about this feature. And an online search of Sony’s support Web site had failed to explain.

What if I turned it off for use with the gyro mount? Tom had suggested trying it both ways. Maybe it was time to take his advice.

I turned SteadyShot off and we hopped into the rental car for a ride. Mike shot video out the window at distant cliffs. We came back to the hotel and looked at the results. The video looked better.

Could this be the answer?

The next morning, we shot some more video with SteadyShot disabled. We used the bungee solution. The light was pretty poor, with thick clouds that sucked the color out of the landscape, so we didn’t get much video. (We were pretty demoralized at this point.) We went back to the hotel to look at it. It looked better, but still not perfect.

We talked about the possibility of it being a smoother flight in the back seat of the helicopter. We resolved to try that the next day.

We took our cameras and tripods down to Lower Antelope Canyon. We spent three hours down there, hiking the whole thing in both directions. Above us, the wind kicked up, sending fine sand down on our heads. I don’t think I’ve ever used my blower or lens brush as many times in a single shoot. We were literally the last people out of the canyon. The Navajos had closed down both Upper and Lower Antelope Canyon due to high wind.

Then we went over to Wahweap Marina. That’s where I shot this telltale footage. I’d turned SteadyShot back on while doing handheld work in Antelope Canyon and had forgotten to turn if off when I put the camera on a tripod. I happened to take a shot of Tower Butte with the camera zoomed all the way in. The wind was howling, blowing at least 30 miles per hour, shaking the tripod ever so gently. Check out the effect on Tower Butte in the sample footage below. Looks like heat rising off the desert in front of the butte, no? It wasn’t.

[qt:https://aneclecticmind.com/wp-content/movies/TowerButte.mov https://aneclecticmind.com/wp-content/movies/TowerButte-poster.mov 480 286]

(I should mention here that the image quality is otherwise inferior for three reasons: image compression for online viewing, full zoom in of camera, and dust storm in progress when shot.)

“Set [STEADYSHOT] to [OFF] when using a tripod (optional), then the image becomes natural.” It now made sense. SteadyShot was doing something weird inside the camera’s software to steady the image. This was introducing wave-like image distortions.

The problem went away as soon as I turned SteadyShot off.

The next day, we went back out for more video. Overnight, there had been slow flurries. Although there was no accumulation in Page, there was a nice dusting uplake on the cliffs and buttes. It made for an interesting contrast. Mike sat in back, behind me as we reshot Hole in the Rock and did a run up the Escalante River for the benefit of my POV.1 “nosecam.” We landed, took a break that included a trip to City Hall and a stop at Starbucks for hot cocoa — it was 0°C in the air and a door was off — and went out for one more shoot. Then we got back to the airport, returned the rental car, packed up the helicopter, and headed home.

We’d flown a total of 12 hours, including ferry time.

That last bit of video was the best of the shoot.

Image Stabilization

Still with me? I know this is a long story, but it does document the entire trial and error process of the shoot. Keep reading. It gets better.

Back home, I found myself with several hours of new video, most of which wasn’t much better than the video I already had. It was time to look into image stabilization.

Yesterday, Mike did a bit of homework for me. He found three possible solutions on the Web, all of which worked with Mac OS (sorry, I don’t do Windows):

  • iStabilize by Pixlock was a $60 solution, available as a demo. I downloaded it and thought I’d try it first.
  • Apple Shake by Apple was a $499 solution that had a boatload of additional features I might or might not use. The demo movie you can find here is very convincing.
  • iMovie ’09 by Apple was software I already had. I had never tried its image stabilization. Frankly, I didn’t think it would be any good. Tom had suggested it, but I thought he was just trying to be nice by suggesting an affordable possibility.

Mike came into my office to ask if I’d tried iMovie yet. I told him I hadn’t. He urged me to do so. We imported a 3-minute clip from my camera archive with image stabilization analysis enabled. The dialog that appeared told us it would take 24 minutes to process.

I spent the time watching a Lynda.com video about the feature so I could see how it worked. When the processing was done, I called Mike back to look at it with me.

The difference was mind-blowing, as you can see in the following video. The original video is in the inset box; the stabilized video is in the main frame. Compare the wobbliness in the inset box to the smoothed out version in the main frame:

[qt:https://aneclecticmind.com/wp-content/movies/StablizationSmall.mov https://aneclecticmind.com/wp-content/movies/StablizationSmall-poster.mov 480 286]

We repeated this exercise for video shot at different times during the weekend. Then video shot on our first [re]shoot. Then video shot around Phoenix in my single-gyro test. All of the video was improved. In many instances, video that had been unusable was now not just usable, but good.

The Final Solution

After all of this trial and error effort, we’ve come up with what we think is the best solution for making high-quality video from a helicopter with high-end consumer camera equipment. (The Sony we used retails for $899.)

  • Mount the camera on at least one gyro. A two-gyro solution like the Micro Gyro Mount would be best, but with a $4,200 price tag, it’s hard to swallow. (A single gyro like the KS-4 is still tough to swallow at $2,000.) Renting is a definite option.
  • Use a bungee cord attached to the aircraft above the camera and attached to the mount near its center of gravity. This reduces the weight in the cameraman’s hands. The bungee should obviously be the right length to ensure comfort for the cameraman. It should also be firmly affixed to the aircraft and camera so it doesn’t spring loose in flight. (Obviously, the camera and mount should be attached to the cameraman or airframe with some other non-stretching device, in case it’s dropped.)
  • Seat the cameraman in the back. There seem to be fewer vibrations back there, at least in an R44 helicopter.
  • Turn OFF software stabilization features in the camera. If they’re as crappy as Sony’s SteadyShot feature, they’ll just make the image worse.
  • Set the camera to Landscape mode, if available, or manual infinite focus.
  • Set the camera to full wide zoom. If you zoom in, you will likely have horrible, shaky footage.
  • Shoot at the highest available resolution. This will come in handy later, when stabilizing video in post production.
  • Use a neutral density filter on the camera. This generally made for a better image. (I did some testing of this before the shoot. The colors seemed richer with the filter on.)
  • Run any video that shows any undesired camera movement — shake, roll, etc. — through image stabilization software after it has been shot.

Obviously, it’s a good idea to practice with your camera setup before the shoot so you’re really familiar with its operations. When you’re spending $450/hour or more for flight time is not the time to be learning. And I shouldn’t have to tell any serious videographer about the importance of light.

Many Thanks

I’d like to end this blog entry with a big thanks to all the folks who helped me come up with this solution:

  • Randy and Bobbi at Kenyon Laboratories were extremely helpful and patient on the phone while I tried to decide whether I should rent their gyro.
  • Arnie at Aerial Exposures provided lots of insight and encouragement. His solutions are a bit more complex than I need or want, but for serious aerial videographers, they’re definitely worth considering.
  • Tom at Blue Sky Aerials provided incredible customer service to ensure that I got the equipment I needed more quickly than I thought possible. He also followed up to see how we were doing during the shoot. I hope to one day be able to justify the purchase of his Micro Gyro Mount, which I think is the best solution for our limited needs.
  • The iLife Development Team did an amazing job incorporating image stabilization features into iMovie ’09. For $79, I have a complete video publishing solution that, while not quite up to the task of a major DVD project, can certainly handle my immediate needs. Way to go, Apple!

I’d also like to throw a big, fat, rotten raspberry in the general direction of Sony and it’s technical support department for wasting my time during two different online chat sessions. If the information I needed were available in the manual or online or in the tech support database, I would have gotten better video from the start, probably with just one gyro.

If you learned anything from all this or you have anything to add, I’d appreciate your comments.

And I hope you’ll keep checking in at Flying M Productions; we hope to have our first DVD available soon.
